Aerospace
One of the major applications is UAV turbojet engines, inspired by real turbojet aircraft, offer enthusiasts speed and an immersive sound experience. These engines are designed with a detailed system including an intake pipe, compressor, combustion chamber, and more, scaled for model aviation.
Material:
♦ Cronidur® 30(X30CrMoN15-1/SV30) stainless steel for both inner & outer rings
♦ With HIP Si3N4 ceramic balls embodying a full ball cageless design for precision.
Precision level: P4/ABEC7, P2/ABEC9
RPM: single bearing could up to 200,000 rpm with oil lubrication.
Working temp.: 250 - 300°C,
Major code: 708(8*22*7mm), 788(8*16*6 mm), 7000(10*26*8mm), 7001(12*28*8mm), 7002(15*32*9mm), 7904(20*37*9mm)
Custom-sized bearings are also available, ensuring compatibility with a broad range of model aircraft.
